Product Introduction

The shipyard gantry crane is a heavy duty gantry crane designed for the shipbuilding industry. It is mainly used for lifting the hull sections, assembling parts and turning over the hull. The load capacity is 100~2000 tons, which can meet the needs of large ship construction.

The equipment consists of a bridge, a trolley running mechanism, a trolley and electrical equipment. The bridge adopts a box-type welded structure, which runs smoothly and is flexible to operate. The shipbuilding gantry crane has multifunctional characteristics, such as lifting up and down, transporting sections, turning over the hull, etc.

WEIHUA provides shipyard gantry crane customized design and manufacturing services to meet the special needs of different shipyards. Free consultation, fast quotation, professional team to provide you with a one-stop crane solution!

Application

Shipyards, dry docks, harbors, ship repair bases and other large water operation areas.
Used for ship repair, construction, equipment installation and heavy parts lifting.
Smoothly runs along the preset track, covering the entire quay and dock area to enhance operational efficiency.

Specification

Loading Capacity	2×50+100t、2×75+100t、2×100+160t、2×150+200t、2×400+400t or customized
Span	50～185m or customized
Lifting Height	28～76/10～50m or customized
Lifting Speed	Main hook lifting: 0~1 m/min or customized Aux.hook lifting: 0~5 m/min or customized
Cross Travel	0~8m/min or customized
Long Travel	0~25m/min or customized
Span	36~230m or customized
Lifting Mechanism	Electric winch trolley(single trolley, upper trolley, lower trolley, double trolley, or customize)
Electrical Parts Brand	SCHNEIDER, SIEMENS, CHNT, or customized
Motor Brand	ABM. ABB, WEG, JMS, XINDALI, SIEMENS, or customized
Reducer Brand	SEW, TAILONG, or customized
Brake Brand	JINGU, ZPMC, or customized
Work Duty	M7~M8
Power Supply	AC-3Phase-220/230/380/400/415/440V-50/60Hz or customized
Control Method	Wireless remote control, cabinet control
Application Area	Shipyard, dock, power station, logistic, etc.
Color	Red, blue, or customized
Working Temperature	-20~40℃ or customized
Protection Class	IP54 / IP55 / IP65
Safety Device	Buffer, current overload protection, overload device, power failure protection, lifting height limit device, traveling limit device

The items listed in above technical parameter table are for reference.

Features

Multi-functional operation ability

Support single lifting, lifting, aerial flip and aerial fine-tuning and other operation modes, adapting to the needs of complex shipbuilding process.

Upper trolley dual main hook design

Equipped with dual main hooks, located on both sides of the main beam, can be independently or synchronously moved laterally 0-2 meters, to enhance the flexibility of lifting.

Lower trolley's main and secondary hook configuration

The main hook and secondary hook are located below the center of the main beam to meet the lifting requirements of different weights and precision.

Up and down trolley cooperative operation

Up and down trolleys can work across each other to realize efficient cooperation and improve work efficiency.
