Scraper-type Circular Stockyard Reclaimer
- Capacity:500-3000T
- Rotary (Stack ):0.01m/min
- Maximum wheel load:250-300KN
- Brand: WeiHua
- Product Type:Mining machinery
Advantages of Scraper-type Circular Stockyard Reclaimer：
Scraper-type Circular Stockyard Reclaimer is a kind of pre-homogenization equipment that adopts continuous synthetic stockpiling and full-section reclaiming for stockpiling and reclaiming. It is mostly used for stockpiling limestone or coal and other bulk materials. Mainly used in building materials, coal, metallurgy, electric power, ports and other industries, suitable for indoor or open storage yards that need to homogenize, store and transfer bulk materials. Mixing and stacking and mixing and reclaiming of materials can be completed at the same time or separately.
Scraper-type Circular Stockyard Reclaimer mainly has three forms: cantilever (top stack side take type), gantry type and bridge type.
Scraper-type Circular Stockyard Reclaimer can be divided into indoor horizontal and outdoor inclined according to the use environment. The diameter of the material yard ranges from p60 to p120 meters.
Scraper-type Circular Stockyard Reclaimer has the characteristics of good homogenization effect, large stock yard reserves, small footprint, high degree of automation, and good environmental performance.
Model | Unit | YG*/*. 60 | YG*/*. 78 | YG*/*. 80 | YG*/*. 90 | YG*/*. 95 | YG*/*. 100 | YG*/*. 110 | YG*/*. 120 |
Stack(Production capacity ) | t/h | 500~800 | 500~800 | 500~1000 | 500~1200 | 800~1500 | 1000~2000 | 1000~2500 | 1500~3000 |
Reclaim (Production capacity ) | t/h | 40~200 | 100~500 | 40~400 | 250~500 | 400~700 | 800~1200 | 1000~1200 | 1200~1500 |
Applicable materials (Material characteristics) | Coal,coke,limestone,bauxite,iron ore,pellet ore,clay and other bulk materials | Coal,coke,limestone,bauxite,iron ore,pellet ore,clay and other bulk materials | Coal,coke,limestone,bauxite,iron ore,pellet ore,clay and other bulk materials | Coal,coke,limestone,bauxite,iron ore,pellet ore,clay and other bulk materials | Coal,coke,limestone,bauxite,iron ore,pellet ore,clay and other bulk materials | Coal,coke,limestone,bauxite,iron ore,pellet ore,clay and other bulk materials | Coal,coke,limestone,bauxite,iron ore,pellet ore,clay and other bulk materials | Coal,coke,limestone,bauxite,iron ore,pellet ore,clay and other bulk materials | |
Density (Material characteristics) | t/m³ | 0.5~2.5 | 0.5~2.5 | 0.5~2.5 | 0.5~2.5 | 0.5~2.5 | 0.5~2.5 | 0.5~2.5 | 0.5~2.5 |
Granularity(Material characteristics) | mm | 0~300 | 0~300 | 0~300 | 0~300 | 0~300 | 0~300 | 0~300 | 0~300 |
Stockyard diameter | m | 60 | 78 | 80 | 90 | 95 | 100 | 110 | 120 |
Storage Capacity | m³ | 15000 | 30000 | 34000 | 52000 | 60000 | 75000 | 86000 | 95000 |
Work (Traveling speed ) | m/min | 0.2~2 stepless speed regulating | 0.2~2 stepless speed regulating | 0.2~2 stepless speed regulating | 0.2~2 stepless speed regulating | 0.2~2 stepless speed regulating | 0.2~2 stepless speed regulating | 0.2~2 stepless speed regulating | 0.2~2 stepless speed regulating |
Dispatching vehicle(Traveling speed ) | m/min | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
Slewing speed of reclaiming | m/min | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 |
Rotary (Stack ) | m/min | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 |
Variable amplitude(Stack ) | m/min | 0.3~0.6 | 0.3~0.6 | 0.3~0.6 | 0.3~0.6 | 0.3~0.6 | 0.3~0.6 | 0.3~0.6 | 0.3~0.6 |
Maximum wheel load | KN | 250/300 | 250/300 | 250/300 | 250/300 | 250/300 | 250/300 | 250/300 | 250/300 |
Recommended steel track | P50/Q80/Q100 | P50/Q80/Q100 | P50/Q80/Q100 | P50/Q80/Q100 | P50/Q80/Q100 | P50/Q80/Q100 | P50/Q80/Q100 | P50/Q80/Q100 | |
Power supply mode | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | |
Contact mode | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | |
Control mode | PLC program control, manual and single action | PLC program control, manual and single action | PLC program control, manual and single action | PLC program control, manual and single action | PLC program control, manual and single action | PLC program control, manual and single action | PLC program control, manual and single action | PLC program control, manual and single action |
