Query-side Container Crane
- Capacity:35-70T
- Work Duty: A6,A7,A8
- Max. wheel load:310KN
- Brand:WeiHua
- Product Type:Port crane
Advantages of quayside container cranes:
The design, manufacture and inspection of quayside container cranes comply with international standards such as FEM, DIN, IEC, AWS, GB, etc. Container cranes have the advantages of flexibility, smooth operation, fast efficiency, high stacking, and small footprint. It is suitable for loading and unloading of heavy cargo in seaports and river ports. With the container spreader, the container can be hoisted. The container crane adopts AC variable frequency speed regulation, PLC control, and installs an intelligent “state monitoring and control system”.
The quayside container crane is a special crane for loading and unloading container ships at the front of the container terminal.
The front reach of the quayside container crane is 70m, the rear reach is 25m, the gauge is generally 26m~30m, and the lifting height is 35m~40m. The full-load/no-load lifting speed reaches 90/180m/min, the trolley running speed reaches 240m/min, and the rated lifting capacity reaches 65t~70t.
Weihua quayside container crane has a number of leading technologies, adopts frequency conversion and multi-transmission feedback technology, the whole machine has excellent performance, large lifting capacity, long forward reach, real-time collection of operating position information, intelligent control of spreader trajectory, and perfect safety protection function , High work efficiency, energy saving and environmental protection.
Model | LJ35/40-23 | Light Type LJ40-23 |
Lifting capacity (without spreader) (t) | 35,40 | 40 |
Work level | A7,A8 | A6,A7 |
Span (m) | 23.47 | 23.47 |
Lifting Height (m) | 12.2~17.8 | 16.5 |
Stack layer | 3/4~5/6 | 5/6 |
Container size | 20',40',45' | 20',40',45' |
Spreader rotation angle | ±5° | ±5° |
Lifting (m/min) | 13/26,23/52 | 12/18,18/28 |
Trolley travelling (m/min) | 50,70 | 24 |
Crane travelling (m/min) | Full load-90, no load-130 | Full load-20, no load-40 |
Max. wheel load (kN) | 310 | 310 |
