Nuclear power crane
- Capacity:130T
- Recommand Track:QU80
- working level:A4
- Brand: WeiHua
- Product Type:Special crane
Advantages of Nuclear power crane:
Nuclear power crane has dozens of specifications of crane equipment, which are divided into mechanical handling hoisting equipment and fuel handling hoisting equipment according to the different objects to be handled.
The main uses of Nuclear power cranes are:
- Lifting of heavy components such as steam generators, pressure vessel roofs, spent fuel containers and generator rotors;
- Handling of new fuel assemblies, spent fuel assemblies and operations of corresponding control rod components and other elements;
- Overhaul of relevant plant components;
- Hoisting of large-scale structural modules in the construction stage of nuclear power plants.
Nuclear power crane installed in the containment building in nuclear power plants, mainly used for handling and installation of pressurizer, steam generator and other equipment in reactor room.
Weihua’s nuclear waste handling CNC crane meets the requirements of the nuclear waste treatment field for high safety, high reliability, and remote intelligent control of cranes. High-precision positioning and anti-sway technology can be promoted and applied to other radioactive pollution treatment fields.
The Nuclear power crane realizes the efficient operation and maintenance of the equipment in the nuclear power pump room through the overall structure optimization and the research of the attitude controllable technology.
Weihua can also provide heavy duty bridge cranes, gantry cranes and other machinery for nuclear power plant wharf used for handling of heavy machinery of nuclear power plants.
Lifting Capacity | - | 130 t | - | - |
Work Duty | A4 | A4 | A4 | |
Span m | 20 | 22 | 24 | |
Lifting Height | Main Hoist m | 10 up rail 30 below rail | 10 up rail 30 below rail | 10 up rail 30 below rail |
Speed | Lifting Main Hoist m/min | 0.37~3.7~6 | 0.37~3.7~6 | 0.37~3.7~6 |
Traveling | 1.4~14 | 1.4~14 | 1.4~14 | |
Traveling Trolley Traveling m/min | 2.5~25 | 2.5~25 | 2.5~25 | |
Dimensions mm | L1 | 1750 | ||
L2 | 1910 | |||
H1 | 1020 | |||
B | 10500 | |||
B1 | 16180 | |||
b1 | 1250 | |||
b2 | 1250 | |||
W | 6500 | |||
D | 3000 | |||
Max. Wheel Pressure | 275 | 283 | 295 | |
Steel Rail Recommended | QU80 | QU80 | QU80 | |
Power Supply | 3 phase 50Hz 380V | 3 phase 50Hz 380V | 3 phase 50Hz 380V | |
Max. Diameter of Cutter | 6.3 | 6.3 | 6.3 |
