Movable Ship Loader
- Capacity:500T-4500T
- Maximum wheel load: 250-350KN
- Recommended steel track:P50-Q80
- Brand: WeiHua
- Product Type:Mining machinery
Advantages of Movable Ship Loader:
Mobile ship loader is a large bulk material machine used in bulk material terminal loading. Generally, the ship loader is composed of a boom, a boom belt conveyor, a telescopic chute, a tail car, a walking device, a gantry, a tower, and a pitching device.
Features of Movable Ship Loader:
- The whole machine can run along the wharf, with good mobility, flexible operation mode and strong adaptability to ship types.
- The boom only performs pitching and telescopic actions. During operation, the loading position of the chute is changed by the cooperation of the boom telescopic and the traveling of the cart. The slewing drive and slewing bearing are omitted, and the whole machine is simpler and lighter.
- The model adopts the herringbone structure type, adopts tubular profiles as the main force-bearing components, and uses less plate-beam welding structure, which reduces the procedures of shearing and welding in the manufacturing process, reduces the difficulty of manufacturing and processing, and shortens the manufacturing cycle.
- The use of telescopic chute can reduce dust pollution during loading.
- The whole machine adopts PLC centralized control, and the main mechanism adopts frequency conversion speed regulation mode, which makes the mechanism run smoothly without impact.
Equipment model | Unit | CSL 500 | CSL 800 | CSL 1200 | CSL 1800 | CSL 2600 | CSL 3200 | CSL 4000 | CSL 4500 |
Production capacity | t/h | 500 | 800 | 1200 | 1800 | 2600 | 3200 | 4000 | 4500 |
Applicable materials | Coal, coke, limestone, bauxite, iron ore, pellet ore, clay and other bulk materials. | Coal, coke, limestone, bauxite, iron ore, pellet ore, clay and other bulk materials. | Coal, coke, limestone, bauxite, iron ore, pellet ore, clay and other bulk materials. | Coal, coke, limestone, bauxite, iron ore, pellet ore, clay and other bulk materials. | Coal, coke, limestone, bauxite, iron ore, pellet ore, clay and other bulk materials. | Coal, coke, limestone, bauxite, iron ore, pellet ore, clay and other bulk materials. | Coal, coke, limestone, bauxite, iron ore, pellet ore, clay and other bulk materials. | Coal, coke, limestone, bauxite, iron ore, pellet ore, clay and other bulk materials. | |
Material Density | t/m³ | 0.5-2.5 | 0.5-2.5 | 0.5-2.5 | 0.5-2.5 | 0.5-2.5 | 0.5-2.5 | 0.5-2.5 | 0.5-2.5 |
Material Particle size | mm | 0-300 | 0-300 | 0-300 | 0-300 | 0-300 | 0-300 | 0-300 | 0-300 |
Cantilever crane pitching | ° | 0~+16 | 0~+16 | 0~+16 | 0~+16 | 0~+16 | 0~+16 | 0~+16 | 0~+16 |
Cantilever crane pitching | ° | 70 | 70 | 70 | 70 | 70 | 70 | 70 | 70 |
Cantilever crane pitching | r/min | 2/4/6/8 | 2/4/6/8 | 2/4/6/8 | 2/4/6/8 | 2/4/6/8 | 2/4/6/8 | 2/4/6/8 | 2/4/6/8 |
Telescopic speed of cantilever crane | r/min | 6(cantilever crane angle0~+16)/3(cantilever crane angle0~+35) | 6(cantilever crane angle0~+16)/3(cantilever crane angle0~+35) | 6(cantilever crane angle0~+16)/3(cantilever crane angle0~+35) | 6(cantilever crane angle0~+16)/3(cantilever crane angle0~+35) | 6(cantilever crane angle0~+16)/3(cantilever crane angle0~+35) | 6(cantilever crane angle0~+16)/3(cantilever crane angle0~+35) | 6(cantilever crane angle0~+16)/3(cantilever crane angle0~+35) | 6(cantilever crane angle0~+16)/3(cantilever crane angle0~+35) |
Chute tube speed(Rotation) | m/min | 0~6 | 0~6 | 0~6 | 0~6 | 0~6 | 0~6 | 0~6 | 0~6 |
Chute tube speed(Stretch) | m/min | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
Conveyer(Belt speed) | m/s | 1.25-4 | 1.25-4 | 1.25-4 | 1.25-4 | 1.25-4 | 1.25-4 | 1.25-4 | 1.25-4 |
Conveyer(Bandwidth) | mm | 1.25-4 | 1.25-4 | 1.25-4 | 1.25-4 | 1.25-4 | 1.25-4 | 1.25-4 | 1.25-4 |
Rail gauge: | m | 650-2400 | 650-2400 | 650-2400 | 650-2400 | 650-2400 | 650-2400 | 650-2400 | 650-2400 |
Maximum wheel load | KN | 250-350 | 250-350 | 250-350 | 250-350 | 250-350 | 250-350 | 250-350 | 250-350 |
Recommended steel track | P50-Q80 | P50-Q80 | P50-Q80 | P50-Q80 | P50-Q80 | P50-Q80 | P50-Q80 | P50-Q80 | |
Power supply mode | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | Cable drum/safety sliding contact line | |
Contact mode | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | Cable drum/safety sliding contact line/wireless | |
Control mode | PLC program control, manual and single action | PLC program control, manual and single action | PLC program control, manual and single action | PLC program control, manual and single action | PLC program control, manual and single action | PLC program control, manual and single action | PLC program control, manual and single action | PLC program control, manual and single action |
