Explosion proof crane

LB explosion-proof single girder bridge crane



  • Explosion-proof Grade: ExdⅡBT4/ExdⅡCT4
  • Work Duty: A4
  • Lifting Height: 6, 9, 12, 18, 24m
  • Brand:WeiHua
  • Product Type:explosion-proof crane

Advantages of LB explosion-proof single girder bridge crane:

LB explosion-proof single girder bridge crane is used in petrochemical, chemical science, coal mining and other industries. Explosion-proof cranes meet European standards, international quality, safety and reliability, and many options and configurations

LB Explosion-proof Single Girder Overhead Crane features:

LB explosion-proof single girder overhead crane is a product built according to the standard. It has novel body structure, beautiful appearance, good performance, easy operation and stable operation. The main features are as follows:

  1. The bridge components of LB explosion-proof single-girder bridge crane are box-shaped main beams, which are automatically welded by submerged arc welding.
  2. The trolley conductive parts of LB explosion-proof single-girder bridge crane use a new I-beam track cable conductive device to ensure reliable performance.
  3. The hoisting mechanism can also be provided with a second set of devices according to different requirements. Improve product reliability. This product is very suitable for the loading, unloading and handling of ordinary goods. It can also be equipped with a variety of special spreaders for special operations. It also has rainproof equipment when working in the open air.
  4. The explosion-proof marks are ExdIIBT4, ExdIICT4, and DIPA21TA, T4.
    Explosion-proof cranes include jib cranes, single-beam cranes, and double-beam cranes. In order to meet the needs of different load requirements and factory operations.

    LB Technical Specifications
    Crane Traveling Mechanism

    Lifting Speed

    m/min

    20

    Reduce Ratio

    58.95

    Motor Type

    Cone-shape Cage

    Motor Power

    KW

    0.8×2,1.5×2,2.2×2


    Motor RPM

    r/min

    1380

    Lifting Mechanism (Electric Hoist)

    Hoist Type

    HB, BCD, BMD

    Lifting Speed

    m/min

    8/0.8,7/0.7,3.5/0.35   8,7,3.5

    Lifting Height

    m

    6, 9, 12, 18, 24

    Traveling Speed

    m/min

    20

    Motor

    Cone-shape Cage

    Work Duty

    A4

    Power Supply

    380V, 50Hz, Three Phase

    Diameter of Wheel

    Φ270mm、Φ400mm

    Wideth of Track

    37mm~70mm

    Explosion-proof Grade

    ExdⅡBT4/ExdⅡCT4
