Hanging girder overhead crane
- Capacity:5-50/10T
- working level:A6
- Brand: WeiHua
- Product Type:Overhead crane
Advantages of girder overhead cranes:
Hanging girder overhead cranes have detachable electric disks. It is especially suitable for handling non-ferrous metal products and materials with magnetic permeability such as steel ingots, section steel, pig iron blocks, etc. Mainly used for re-rolling line and finished product warehouse of iron and steel enterprises. Shipyard steel yard, blanking workshop, etc.
Features of hanging girder bridge crane:
- The lifting capacity of the girder bridge crane includes the self-weight of the electromagnet, and the total weight of the crane does not include the self-weight of the electromagnet.
- The structure is simple, the force is balanced, and the disassembly is convenient.
- The single motor drives a single drum or a double drum structure to ensure the synchronization of the lifting objects.
- The metal structure of the hanging beam adopts the box beam type welded by steel plates, and the electromagnetic suction cups on the hanging beam can be disassembled, which is convenient for maintenance.
- The overload limiter adopts dual sensors and dual channels for input respectively, and sets the control points for the single lifting point and the resultant force of the two lifting mechanisms respectively, which makes the use of the crane more convenient and safer.
According to customer needs, the crane can be equipped with our company’s patent – electric swing, which is the world’s leading technology. The same industry takes the lead in realizing lean management and lean production, which promotes the further improvement of product quality.
Capacity | t | 7.5+7.5 | 10+10 | 16+16 | 17.5+17.5 |
Span | m | 28 | 28 | 28 | 28 |
Work duty | -- | A7 | A7 | A7 | A7 |
Max. lift height | m | 12 | 16 | 16 | 16 |
Lift speed | m/min | 12.9 | 11.9 | 12 | 12 |
Trolley speed | m/min | 42.7 | 38 | 37.9 | 39.8 |
Crane speed | m/min | 100 | 91.3 | 114 | 114 |
Hoisting motor power | KW | YZR280M-10/55 | YZR315M-10/63 | YZR355M-10/90 | YZR355M-10/90 |
Trolley traveling power | KW | YZR200L-8/2×15 | YZR160M2 | YZR160L-6/11 | YZR160L-6/11 |
Crane traveling power | KW | YZR200L-8/2×15 | YZR180L-82×15 | YZR225M-8/22×2 | YZR225M-8/22×2 |
Magnet weight | kg | -- | -- | -- | -- |
Trolley weight | kg | 14280 | 14980 | 16.23 | 16.50 |
Crane weight | kg | 54280 | 62865 | 89.5 | 100.6 |
Max. wheel load | KN | 240 | 280 | 39.0 | 40.6 |
Rail recommended | kg/m | 38.43 | 38.43 | QU70 | QU100 |
Power supply | AC 3P | 380v 50Hz | 380v 50Hz | 380v 50Hz | 380v 50Hz |
