Dam crest gantry crane
- Capacity:600T
- Work classifications:Q3(middle class)
- Crane rail recommended:QU80
- Brand: WeiHua
- Product Type:Road overhead & Water conservancy
Advantages of Dam crest gantry crane:
Dam crest gantry crane is a common equipment in hydraulic engineering, mainly used for the opening and closing of sluice gates. The appearance of the Dam crest gantry crane improves the speed of gate opening and closing, and also has a good auxiliary role for the operator.
The cart of the Dam crest gantry crane moves in the direction of the dam body, and the trolley moves in the direction of the water flow. Generally, there are multiple sets of grab beams, which can open and close the multi-hole gates and trash racks on different centerlines of the dam. The upstream or downstream outriggers of the gantry crane are equipped with slewing cranes, and the slewing radius of each slewing crane can reach 180°, which can assist the transportation and installation of the equipment on the dam.
Features of Dam crest gantry crane:
- Large opening and closing force, suitable for opening and closing of gates of large water conservancy and hydropower stations;
- The cart moves in the direction of the dam body, and the cart moves in the direction of the water flow;
- Double slewing mechanism, the working range of the door crane is increased;
- Easy to operate and maintain, and can realize on-site and remote control operation.
Lifting capacity | KN | 630 |
Span | m | 4.5 |
Lifting height | m | 28(under rail 21m) |
Work classifications | Q3(middle class) | |
Main lifting Speed | m/min | 1.57 |
travelling Speed | m/min | 19.4 |
Total power | KW | 64 |
Crane rail recommended | QU80 | |
Max. wheel loading | KN | 577 |
Power | Three-phase AC 50Hz 380V |
