Wall Traveling Jib Crane

مقدمة المنتج

Wall-Mounted Jib Crane

A wall traveling jib crane is a movable small material handling device developed based on a wall bracket jib crane that often works with an electric hoist. Its running track is fixed on the concrete columns of the plant and can be moved longitudinally along the track, while the electric hoist can realize lateral movement and vertical lifting and lowering functions on the cantilever. The design of wall-traveling jib cranes significantly improves the operational coverage and optimizes the utilization of plant space, which is particularly suitable for use in factories, workshops, production lines, assembly lines, machine tool loading and unloading operations, as well as warehouses, wharves and other places of heavy lifting tasks.

A wall traveling jib crane is a type of jib crane that can be moved on an elevated track on a wall or other support structure, offering a variety of load capacities, usually ranging from 500 lbs to several tons, depending on the specific model. The main girder construction is divided into two forms: single girder and double girder, where the single girder includes both fixed and slewing jibs. The size of the running track can be customized according to user requirements.

Structures and Parts

Wall-traveling Jib Crane is mainly composed of the cantilever beam, slewing device electric chain hoist, and other parts.

• The electric chain hoist is responsible for the lifting function and can move horizontally and reciprocally on the cantilever beam.
• The jib arm can rotate 180° or 360°, depending on the design. It drives the roller through the reducer in the slewing device to realize flexible slewing movement. The length of the jib arm can be customized to suit your specific workspace and load-handling requirements.
• The electrical control system is integrated into the electric chain hoist, which is compact and easy to maintain.
• The rail system can be installed along various types of walls, such as solid concrete or steel structures.

مواصفة

المزايا

• Compact structure, optimized design: takes up very little space, maximizes the use of plant height and width, suitable for space-restricted operating environments, especially suitable for multi-story workshops or narrow sites.
• Frequency conversion speed regulation, smooth operation: step-less speed regulation is realized by frequency conversion technology and precise speed control; the lifting and moving process is smooth, reducing the material shaking and improving the operation precision and safety.
• Multiple safety protection, safe and reliable: equipped with overload protection, limit switch, and emergency braking devices, effectively prevent accidents and ensure operational safety.
• Integrated transmission, energy saving, and high efficiency: adopting high efficiency integrated transmission technology, reducing energy loss, improving operation efficiency,y and reducing long-term cost.
• Silent drive, low noise, and environmental protection: the use of advanced silent drive technology to reduce the noise of the equipment, in line with environmental requirements, suitable for na oise-sensitive production environment.

طلب

Wall-traveling jib cranes are suitable for short-distance, high-frequency, intensive lifting operations. It has the features of high efficiency, energy saving, space-saving, easy operation as well as easy maintenance, and is widely used in the scenarios of machinery manufacturing and assembly workshops. The application industries and scenarios of wall-traveling jib cranes include:

• تصنيع: material handling of production lines, lifting of assembly line parts, loading and unloading of machine tools.
• Warehousing and logistics: heavy object handling, cargo loading and unloading, and stacking in warehouses.
• Automotive industry: lifting of automobile assembly line parts, equipment handling in repair workshops.
• Mechanical processing: handling of heavy machinery parts, equipment installation, and maintenance.
• Food and beverage industry: production line equipment maintenance, heavy raw material handling.
